STAHL 6002/4128-0100-152-1110-11-8500 Zóna 1-es 22W-os LED lámpa

• Részletek

Részletek

Zone 1
2 G | Gb / Zone 2 | 3 G | Gc/21
2 D | Db / Zone 22 | 3 D | Dc
Certificates: ATEX (IBE), IECEx (IBE), India (PESO)
Lamp: LED
Light colour: 5000 K – neutral white
Degree of protection IP (IEC 60598): IP66/IP67
Enclosure material: Polyester resin
Diffuser: With diffuser
Installed terminal strip: PE + N + L1 + L2 + L3
Max. solid connection terminals: 6 mm²
Type of connection cable: Finely stranded, solid
Disconnection of the luminaire: No
Through wiring: with 5 conductors 2.5 mm2
Drilled holes: 3 x M25
max. ambient temperature: +50 °C
min. ambient temperature: -40 °C
Frequency range: 50 - 60 Hz
Lamp wattage: 22 W
AC rated operational voltage: 100 - 240 V
